1. Adjustable water temperature: Water cooled type chiller outptu chilled water from +5 to +30℃.Water temperature and flow rate can be designated and adjustable in control range.
2. Stable performance: Screw compressor chiller is smple structure, less moving parts, low failure rate, high safety factor, large cooling capacity.
3. Power saving and energy saving: Screw chiller capacity control can be four (100%-75%-50%-25%) or three (100%-66%-33%) automatic adjustment ability, which can effectively save energy consumption according to the actual use of heat load, so as to effectively save energy.
4. Long service life: Shell and tube evaporator and condenser, the welded structure is simple, sturdy structure, high quality, compact structure, long life and so on.
5. Simple installation and operation: This 60hp extruder chiller can be a central chiller to cool several processes, easy installation and operation with lower cost. It can work after connecting the production lines with water pipes. Small size, easy to install, and simple to operate.

The difference between Air-cooled chiller and Water-cooled chiller

An air-cooled chiller refers to a chiller system that uses the ambient air surrounding the condensing unit to cool and condense the refrigerant back into a liquid. In other words, the air cooled chillers use fans for chiller's refrigerant dissipate heat.

The most common types of water cooled chillers use water from an external cooling tower to cool the refrigerant in the condenser.They need to install cooling tower and cooling pump for operation. since they require a constant supply of water for cooling, they might not be suitable for locations with water shortages or restrictions.

Industrial water cooled Chiller installation

This water cooled screw chiller system including the items below:

Chiller
Cooling tower
Condenser cooling pump
process chilled water pump

1. Install the chiller unit in a steady, ventilated and easy-installation place, avoid corrosion, pollution and weather-beaten.
2. Choose a suitable cooling tower to match the chiller unit.
3. Pipeline should be installed according to the dimension of the chiller. Do not reduction the size of the hose, or it will affect the refrigeration effect and increase the power consumption.
4. The chiller unit must be installed more than 1 meter away from the wall, so that it is easy to install, maintain and adjust

How to select the model of the chiller ?

• We need to know the heat load of your process or chiller cooling capacity.
• Required water temperature, water pressure and flow rate.
• Application and power supply in local.
• Max. Ambient temperature in summer day
• Customized special specifications are acceptable. Contact us for more chiller Specification by number +86 13923791048.

Anges has a senior design and development team, with the ability of continuous innovation and according to customer requirements, to provide the best customized solutions.

We provide a full range of industrial refrigeration equipment solutions and engineering for customers around the world, ranging from small refrigeration units to large refrigeration units, such as energy saving inverter chillers, large capacity screw chillers, small capacity scroll chillers and integrated central water chillers, which are widely used in rubber and plastic, beverage filling and food processing, pharmaceutical chemical industry, electronic circuit, electroplating coating, printing industry, beverage daily, laser cutting, water jet and so on.

Anges Team

Our company has professional technical research and development personnel, all kinds of production technical personnel, professional marketing team, perfect after-sales service guarantee system. Our R & D team and professional technical support team have been engaged in R & D and technical support work for a long time, accumulated rich experience, with the capability of program design, to provide customers with personalized product solutions.

R&D

Anges has a R&D team of dozens passionate experts, and keeps in close touch with foreign professionals from Australia. So far, we are granted a number of R&D patents.

Quality

Anges has passed ISO9001 quality management system certification. Thanks to our strict quality control system through each step of designing, manufacturing, inspection and packaging, all the Anges industrial chillers are approved in accordance with CE certification.
